Designed exclusively for 8th generation Intel® Core™ processors to maximize connectivity and speed with integrated M.2 with Intel® Optane™ Memory compatibility and USB 3.1 Gen2
5X Protection III Hardware-level safeguards provide component longevity and reliability
FanXpert 2+ delivers advanced fan control for dynamic cooling
ASUS OptiMem improves memory stability and performance by improving trace isolation between PCB layers to maintain signal integrity even at higher frequencies
On-board 8-Channel HD Audio provides warm, immersive crystal-clear surround sound
specs
General
Product Type
Motherboard - micro ATX
Chipset Type
Intel B360 Express
Compatible Processors
Pentium, Celeron, Core i5, Core i3, Core i7 (supports 8th Generation Intel Core i3 / i5 / i7 / Pentium / Celeron)
Processor Socket
LGA1151 Socket
Max Processors Qty
1
Manufacturer
Asus
Expansion / Connectivity
Expansion Slots
1 x CPU
2 x DIMM 288-pin
1 x PCIe 3.0 x16
2 x PCIe 3.0 x1
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA
SATA-600 / PCIe 3.0 -connectors: 1 x M.2
Internal Interfaces
4 x USB 2.0 - header
2 x USB 3.1 Gen 1 - header
1 x serial - header
1 x SPDIF out - header
1 x audio - header
1 x speaker - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Processor
Max Supported Qty
1
Installed Qty
0
Interface Provided
Qty
1, 2
Type
DVI-D, LAN (Gigabit Ethernet), PS/2 keyboard, PS/2 mouse, USB 2.0, USB 3.1 Gen 1, VGA, audio line-in, audio line-out, microphone
Connector Type
mini-jack
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network Controller
Realtek RTL8111H
Network
Gigabit Ethernet
Processor / Memory / Storage
Max Supported Qty
1
Memory
Max Allocated RAM Size
1 GB
Miscellaneous
Product Type
motherboard
Included Accessories
1 x M.2 screw, I/O back plate
Audio
Audio Codec
Realtek ALC887
Compliant Standards
High Definition Audio
Video
Video Output
graphics adapter (CPU required)
Graphics
Max Allocated RAM Size
1 GB
Audio Output
Compliant Standards
High Definition Audio
Type
sound card
Audio Codec
Realtek ALC887
Audio
High Definition Audio (8-channel)
RAM
Max Supported Size
32 GB
Features
Intel Extreme Memory Profiles (XMP), dual channel memory architecture
LAN
Network Interfaces
Gigabit Ethernet
Network Controller
Realtek RTL8111H
Supported RAM
Bus Clock
2400 MHz, 2133 MHz, 2666 MHz
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Max Size
32 GB
Technology
DDR4
Supported RAM Integrity Check
Non-ECC
Header
Brand
ASUS
Product Line
ASUS
Model
PRIME B360M-K
Packaged Quantity
1
Mainboard
Form Factor
micro ATX
Processor Socket
LGA1151 Socket
Compatible Processors
Celeron, Core i3, Core i5, Core i7, Pentium
Compatible Processors Comments
supports 8th Generation Intel Core i3 / i5 / i7 / Pentium / Celeron
Chipset Type
Intel B360 Express
Supported RAM Technology
DDR4 SDRAM
Supported RAM Speed
2133 MHz, 2400 MHz, 2666 MHz
Supported RAM Integrity Check
non-ECC
Supported RAM (Registered or Buffered)
unbuffered
RAM Slots
2 DIMM slots
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Mainboard Features
BIOS Type
AMI
BIOS Features
ACPI 6.1 support, ASUS EZ Flash 3, ASUS Quiet Thermal Solution, Multilingual BIOS, SMBIOS 3.1 support, UEFI BIOS
Sleep / Wake Up
wake on LAN (WOL), wake on PME
Hardware Features
ASUS 5X Protection III, ASUS DIGI+ VRM, ASUS EPU (Energy Processing Unit), ASUS EZ DIY, ASUS Fan Xpert, ASUS OptiMem, ASUS Overvoltage Protection, ASUS Q-Design, ASUS SafeSlot Core, ASUS Stainless Steel Back I/O, CrashFree BIOS 3, Fanless Design Heatsink, Intel Clear Video HD Technology, Intel InTru 3D Technology, Intel Insider, Intel Quick Sync Video, Intel Turbo Boost Technology 2.0, LANGuard, Preboot eXecution Environment (PXE), Q-DIMM, audio jack detect technology, jack retasking
Interfaces
Storage
M.2 socket, Serial ATA-600
Storage Ports
6 x SATA-600, 1 x M.2
USB 3.0 / FireWire
USB 3.1 Gen 1
USB / FireWire Ports Configuration (Active)
2 x USB 3.1 Gen 2 + 2 x USB 3.1 Gen 1 + 2 x USB 2.0
Cable Details
Type
Serial ATA cable
Included Qty
2
Expansion Slots
Total Qty
1, 2
Type
CPU, DIMM 288-pin, PCIe 3.0 x1, PCIe 3.0 x16
Dimensions & Weight
Width
8.9 in
Depth
7.3 in
Software
Software Included
ASUS AI Charger, ASUS AI Suite III, ASUS EZ Flash 3, File Transfer, PC Cleaner, drivers & utilities
Video Memory
Max Allocated RAM Size
1 GB
Storage Interfaces
Interface
Serial ATA-600, Serial ATA-600 / PCIe 3.0
Connector(s)
1 x M.2, 6 x 7pin Serial ATA
Internal Interfaces
Type
SPDIF out, USB 2.0, USB 3.1 Gen 1, audio, serial, speaker
Connector Type
header
Qty
1, 2, 4
Features
BIOS Type
AMI
BIOS Features
Multilingual BIOS, ASUS Quiet Thermal Solution, UEFI BIOS, ASUS EZ Flash 3, ACPI 6.1 support, SMBIOS 3.1 support
Hardware Features
Jack retasking, ASUS Q-Design, Q-DIMM, ASUS EZ DIY, CrashFree BIOS 3, audio jack detect technology, ASUS EPU (Energy Processing Unit), ASUS Fan Xpert, Intel Turbo Boost Technology 2.0, ASUS DIGI+ VRM, Intel Clear Video HD Technology, Fanless Design Heatsink, Intel InTru 3D Technology, Intel Insider, Intel Quick Sync Video, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, LANGuard, ASUS Overvoltage Protection, ASUS 5X Protection III, ASUS SafeSlot Core, ASUS OptiMem
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
General
Manufacturer
Asus
