CPU (MAX SUPPORT) |
i9 |
SOCKET |
1151 |
CHIPSET |
Intel® H310 Chipset |
DDR4 MEMORY |
2666/ 2400/ 2133 MHz |
MEMORY CHANNEL |
Dual |
DIMM SLOTS |
2 |
MAX MEMORY (GB) |
32 |
PCI-E X16 |
1 |
PCI-E GEN |
Gen3 |
PCI-E X1 |
2 |
SATAIII |
4 |
TPM (HEADER) |
1 |
LAN |
10/100/1000*1 |
USB 3.1 PORTS (FRONT) |
2(Gen1, Type A) |
USB 3.1 PORTS (REAR) |
2(Gen1, Type A) |
USB 2.0 PORTS (FRONT) |
2 |
USB 2.0 PORTS (REAR) |
4 |
SERIAL PORTS(FRONT) |
1 |
AUDIO PORTS (REAR) |
Realtek® ALC887/ ALC892/ ALC897 Codec |
DVI-D |
1 |
VGA |
1 |
HDMI |
1 |
DIRECTX |
12 |
FORM FACTOR |
m-ATX |
OPERATING SYSTEM |
Support for Windows® 10 64-bit |
