DESCRIPTION
Â
300MBPS WIRELESS N SPEED
Complying with the 802.11n standard, N300RH delivers Wi-Fi speed up to 300Mbps, satisfying all internet activities like network communication, online gaming and video streaming.
Â
EXCELLENT WI-FI CONNECTION OVER LONG DISTANCE
Stable and fast Wi-Fi connection over long distance makes your home network sharing more enjoyable in every corner.
Â
EXTENSIVE WIRELESS COVERAGE
Two 11dBi antennas and high output power design significantly enhances the signal stability and provides extensive Wi-Fi range with less dead spots.
Â
ENJOY YOUR IPTV
Simply set up IPTV related information on N300RH's Easy Setup page, you can enjoy smooth IPTV and fast Wi-Fi at the same time.
Â
FLEXIBLE POWER SUPPLY BY PASSIVE POE
Long distance power supply can be achieved by Passive PoE, making the deployment more flexible and easy.
Â
MULTIPLE NETWORKS AVAILABLE
More than one Wi-Fi networks can be added to provide secure Wi-Fi access for guest sharing your home or office network.
Â
PARENTAL CONTROL
Wi-Fi Schedule helps parents to set up time schedule for Wi-Fi network access, effectively preventing children caught in the Web, better for parental control.
EASY SETUP
For Wi-Fi devices first connected to N300RH, the log in page will show up automatically, configuration has never been so easier.
Â
FEATURES
- Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
- Up to 300Mbps data rate for Wi-Fi network.
- Advanced MIMO technology enhances the throughput and wireless coverage.
- Supports DHCP, Static IP, PPPoE(dual access), PPTP(dual access), L2TP(dual access) broadband functions.
- Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
- Connects to secure network easily and fast using WPS.
- Supports IP, Port, MAC, URL filtering and Port Forwarding.
- QoS: Bandwidth Control based on IP/MAC.
- Multi-SSID allows user to create multiple SSIDs according to their needs.
- Supports VLAN function for IPTV and other internet services.
- Universal repeater and WDS function for easy Wi-Fi extension.
- SSH Server function ensures the security of remote login.
- High output power expands the wireless coverage and improve connection stability.
- Supports TR-069 protocol for remote centralized management.
- Supports passive PoE power supply.
Â
ADDITIONALGENERAL
BRAND TOTO LINK
MODEL N300RH
COLOR White
TYPE Wireless Routers Without Modem
CONTROLS RST/WPS Button
LED INDICATOR 1*Power, 1*CPU, 1*Wireless, 1*WAN, 4*LAN
FREQUENCY 2.4~2.4835GHz
POWER SUPPLY 12V DC/1A
OTHER FEATURES Network: VLAN, IPv6Â
Operation ModeÂ
Wireless ISP Client Router
Wireless Client
Repeater(Range Extender)
Router
Bridge with AP
Client
PRODUCT DIMENSIONS 180 x 106 x 24.5 mm
WEIGHT 455 g
Â
OPERATING CONDITIONS
Â
OPERATING HUMIDITY 10%~90% non-condensing
TEMPERATURE 0℃~40 ℃ (32 ℉~104℉)
Â
SUPPORT PROTOCOLS
Â
STANDARD FEATURES IEEE
STANDARD IEEE IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Â
WIRELESS FEATURES
Â
SIGNAL RATE 802.11n: up to 300Mbps
802.11g: up to 54Mbps (dynamic)
802.11b: up to11Mbps (dynamic)
EIRP < 20dBm (For countries using CE standard)
< 27dBm (For countries using FCC standard)
OTHER FEATURES Reception Sensitivity
270M: -61 dBm@10% PER
135M: -65 dBm@10% PER
54M: -68 dBm@10% PER
11M: -85 dBm@8% PER
6M: -88 dBm@10% PER
1M: -90 dBm@8% PER
Wireless Functions: Multiple SSID, MAC Authentication, Universal Repeater, WDS, WPS
Schedule: Reboot Schedule, Wireless Schedule
CONNECTIVITY
ANTENNA External
NUMBER OF LAN PORTS 34
NUMBER OF WAN PORTS 1
WAN 10/100Mbps RJ45 WAN Port
LAN 10/100Mbps RJ45 LAN Ports
NUMBER OF ANTENNAE 2 detachable antennas
ANTENNAE CAPACITY 11dBi
SECURITY
ENCRYPTION 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
FIREWALL MAC Filtering, IP Filtering, Port Filtering, URL Filtering, Port Forwarding, DMZ
ADDITIONAL FEATURES
OTHER FEATURES Management: Firmware Upgrade, QoS, TR-069 config, DDNS, Access Control, SSH Server
SALES PACKAGE
IN THE BOX N300RH Wireless Router *1
11dBi antennas*2
Power Adapter *1
Ethernet Cable *1
Quick Installation Guide *1
WEIGHT 750.0000
