Frequency Bands | LTE -B1/B3/B5/B7/B8/B20/B38/B40 UMTS -Â Band 1, 8 GSM - 850/900/1800 MHz |
Bandwidth | LTE Band -Â 1.4/3/5/10/15/20 MHz, comply with 3GPP |
Modulation | Downlink -Â QPSK/16-QAM/64-QAM, comply with 3GPP Uplink -Â QPSK/16-QAM, comply with 3GPP |
RF Power Level | LTE FDD -Â Power Class 3 (23 +/-2dBm) UMTS -Â Power Class 3 (24 +1.7/-3.7dBm) EDGE -Â Power Class E2 (GSM850/900: 27dBm; DCS/PCS: 26dBm) GPRS -Â GSM850/900 Power Class 4: 33dBm; DCS/PCS Power Class 1: 30dBm) |
Data Rate | 4G - 3GPP Cat. 4, Downlink/Uplink up to 150Mbps/50Mbps 3G -Â 3GPP Downlink/Uplink up to 42Mbps/5.76Mbps 3G - 3GPP2 Downlink/Uplink up to 3.1Mbps/1.8Mbps (MDM9607 only) 2G -Â EGPRS Class33 Downlink/Uplink up to 296Kbps/236.8Kbps |
 Wi-Fi | Frequency - 2.4GHz Protocol - 802.11b/g/n, 20/40M Channel 1 ~ 11 Antenna - Internal Antenna ( 2 x 2 ) |
Interface | 2x 1000Mbps LAN 1x 1000Mbps LAN + 1x 1000Mbps WAN (Optional) RJ11 -Â CS Voice, VoLTE (Subject to local carrier support) USIM -Â Single, 2FF Antenna -Â 2x LTE External Antenna Power Jack - DC Input (12V 1A) |
LED | Power - Power Status Indicator (Red & Green) Internet - Internet Connection Status Indicator/(4G/3G/2G Network Status Indicator)(RGB tri-colour LED) Wi-Fi - Wi-Fi Status Indicator(Green single LED) Signal Strength - 4 LED for signal strength (Four Green single LED) |
Button | Power - On/off WPS - Enable /Disable WPS Reset - Restore Factory Settings |
WebUI | System Mobile Service Router |
Dimension | 129 x 117 x 35mm |
Weight | 195g |
