Description
Â
EXTREMELY HIGH SPEED EXPERIENCE
A2004NS adopts the next generation 802.11ac technology and offers wireless speed up to 1167Mbps, optimized for music, HD video and online gaming.
Â
SIMULTANEOUS DUAL BAND
With 2.4GHz (300Mbps) and 5GHz (867Mbps) working concurrently, A2004NS ensure high stability, less interference and high data rate for wireless connections.
Â
MULTI-FUNCTION USB 2.0 PORT
With a USB 2.0 port, A2004NS can be used as a FTP server, Samba server or URL server while connected to a NAS(Network attached storage); or be used as a charger while connected to smart phone or tablets.
Â
FIVE GIGABIT PORTS FOR SUPERIOR DATA TRANSFER
A2004NS provides one gigabit WAN port and four gigabit LAN ports for ultrafast wired network.
Â
HEAT-DISSIPATION DESIGN
New cooling design supports long-term operation with high reliability and makes the device look more beautiful.
Â
MULTIPLE WIRELESS NETWORK FOR ACCESS CONTROL
Multi-SSID function can isolate one wireless network to several different WiFi spots for security and good access management.
Â
VPN(VIRTUAL PRIVATE NETWORK) FOR REMOTE INFORMATION SHARING
Based on PPTP protocol, 5 VPN tunnels are provided to secure remote access. It not only protects your data privacy, but also is convenient for networking.
Â
OUTSTANDING BANDWIDTH CONTROL WITH QOS
Intelligent QoS efficiently improves the bandwidth utilization and is better for network priority control.
Â
Features
Â
- Complies with 802.11ac/a/b/g/n standards.
- Simultaneous 2.4GHz 300Mbps and 5GHz 867Mbps.
- Equipped with four high gain antennas.
- Adopts advanced MIMO technology.
- Supports PPPoE, DHCP and Static IP broadband functions.
- Provides five Gigabit Ethernet Ports.
- Provides Multiple SSID and QoS function.
- Provides 64/128-bit WEP, WPA, WPA2 and WPA-Mixed security.
- Connects to secure network easily and fast using WPS.
- Supports IP, MAC, URL filtering and Port Forwarding.
- Supports universal repeater and WDS function.
- Provides a multi-functional USB2.0 port.
- The VPN server can not only protect the privacy of your information, but also simplify network management.
ADDITIONALGENERAL
Â
BRAND: TOTO LINK
MODEL A2004NS
COLOR White
TYPE Wireless Routers Without Modem
CONTROLS 1 *WPS Button
1 *RST Button
LED INDICATOR 1 *Power, 1 *CPU, 1 *2.4G Wireless, 1 *5G Wireless, 1 *WAN, 4 *LAN, 1*USB
FREQUENCY 2.4GHz/5GHz
POWER SUPPLY 12V DC/2A
OTHER FEATURES WAN Type: PPPoE/DHCP/Static IP
PRODUCT DIMENSIONS 182.3 x 133.8 x 25.9 mm
WEIGHT 725 g
SUPPORT PROTOCOLS
STANDARD FEATURES IEEE
STANDARD IEEE IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
WIRELESS FEATURES
SIGNAL RATE 2.4GHz: Up to 300Mbps
5GHz: Up to 867Mbps
EIRP 2.4GHz < 20dBm
5GHz < 23dBm
OTHER FEATURES Channels: 2.4GHz: 1-11 (North America), 1-13 (General Europe), 1-14 (Japan) / 5GHz: 36~165
Reception Sensitivity
2.4G: 11b: <-79dbm / 11g: <-68dbm / 11n: HT20<-65dbm HT40: <-61dbm
5G: 11a:<-68dbm / 11ac: HT20<-65dbm HT40: <-61dbm HT80: <-51dbm
Wireless Functions: Multiple SSID, Wireless Bridge, MAC Authentication, WDS, WPS,Wireless Scheduler
NAT / Routing: Port Forwarding, DMZ/Twin IP, Port Trigger
CONNECTIVITY
ANTENNA Internal
NO. OF USB PORTS 1
NUMBER OF LAN PORTS 4
NUMBER OF WAN PORTS 1
WAN 10/100/1000Mbps WAN Port
LAN 10/100/1000Mbps LAN Ports
NUMBER OF ANTENNAE 4
ANTENNAE CAPACITY 2 *5dBi Fixed Antennas(2.4GHz ), 2 *5dBi Fixed Antennas(5GHz )
SECURITY
ENCRYPTION 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
FIREWALL Internet Access Control: IP/MAC Address filtering
Net Detector
ADDITIONAL FEATURES
VPN Yes
OTHER FEATURES Utility: VPN, DDNS, WOL, Host Scan, IPTV
Traffic: QoS, Connection Control
System: System Log, Admin Setup, Firmware Upgrade, System Time, Config Backup and Restore
USB Storage: FTP Service, Samba Service, URL Service
SALES PACKAGE
IN THE BOX A2004NS Wireless Router *1
Power Adapter *1
Ethernet Cable *1
Quick Installation Guide *1
WEIGHT 1.2000
WARRANTY
WARRANTY PERIOD 1Â Year Manufacturer Warranty
