Powered by 5th-generation Wi-Fi (5G Wi-Fi), the 802.11ac chipset gives the RT-AC59U super-fast wireless speeds. RT-AC59U delivers up to 867 Mbps at 5 GHz, also with 4x4 600 Mbps at 2.4 GHz which is 2X faster than current 300 Mbps routers.
The RT-AC59U is equipped with four Gigabit LAN ports that can pump up to 4Gbps simultaneously. Smart TVs, game consoles, cable boxes, media players, NAS storage devices and more can now have their own dedicated ports, making the RT-AC59U your home's lag-free media hub.
Â
Model Name |
RT-AC59U |
Network Standard |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 |
Product Segment |
AC750 complete AC performance : 300+433 Mbps |
Data Rate | 802.11a: up to 54 Mbps 802.11b: up to 11 Mbps 802.11g: up to 54 Mbps 802.11n: up to 600 Mbps 802.11ac: up to 867 Mbps |
Antenna | External antenna x 4 |
Transmit/Receive | MIMO technology 2.4 GHz 4 x 4 5 GHz 2 x 2 |
Processor | 74Kc MIPS processor with 64 KB I-Cache and 32 KB D-Cache, targeted to operate at up to 775 MHz |
Memory | 16 MB Flash, 128 MB RAM |
Boost Speed | Beamforming: 802.11ac Explicit transmit beamforming (TxBF) and Legacy implicit TxBF for both beamformer and beamformer 256-QAM high data rate 20/40/80 MHz bandwidth |
Operating Frequency | 2.4G Hz / 5 GHz |
Router APP | ASUS Router APP: Yes |
Wireless | IPv6:Yes MU-MIMO: No Wi-Fi Encryption:Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise UTF-8 SSID: Yes Guest Network: Yes Maximum Guest Network rule:2.4GHz x3, 5GHz x3 Guest Network Encryption: Open system, WPA/WPA2-Personal WPS: Yes Wi-Fi MAC address filter: Yes Maximum MAC filters:64 Wireless scheduler: Yes Airtime fairness: Yes RADIUS Server: Yes Universal beamforming: Yes Explicit beamforming: Yes |
WAN | Internet Connection Type:PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN: No WAN Aggregation: No 3G/4G LTE dongle: Yes Android tethering: Yes Port forwarding: Yes Maximum port forwarding rule:64 Port triggering: Yes Maximum port triggering rule:32 DMZ: Yes DDNS: Yes NAT Passthrough:PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay |
LAN | DHCP Server: Yes IGMP snooping: Yes IPTV: Yes LAN Link Aggregation: No Manually assign an IP address: Yes |
VPN | VPN Client L2PT: Yes VPN Client OVPN: Yes VPN Client PPTP: Yes VPN Server IPSec: No VPN Server OVPN: Yes VPN Server PPTP: Yes VPN Fusion: No |
USB Application | File System: FAT16, FAT32, NT3G, ext2, ext3 HDD hibernation: Yes Safely Remove disk: Yes AiCloud: No Download master: No AiDisk: Yes Media Server: Yes Time Machine: No Samba Server: Yes FTP Server: Yes Shared Folder privileges: Yes |
Ports |
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4 |
Power Supply |
AC Input: 100V~240V(50~60Hz) |
Weight | 348 g |
Administration | Operating mode: Accesspoint, Mediabridge, Router Operating system: ASUSWRT Free OS upgrade: Yes Firewall: Yes Maximum Firewall keyword filter:64 Maximum Firewall network service filter:32 Maximum Firewall URL filter:64 Wake on LAN (WOL): Yes SSH: Yes Configuration backup and restore: Yes Diagnosis tools: Yes Feedback system: Yes System log: Yes |
