Physical Input Interface | 1x Fast Ethernet RJ45 WAN/POE port (supports IEEE 802.3at POE) 1x Fast Ethernet RJ45 LAN port 1x DC Jack input |
LED | 1x Multi-colour LED 1x WAN LED 1x LAN LED |
Button | 1x Reset button |
Power Supply | PoE (802.3af) or External 12VDC 1A power supply |
Antenna | 2.4GHz 802.11n: 2x 5dBi |
Mounting | Ceiling / Wall (mounting kit included) |
Frequency | 2.4GHz 802.11b/g/n: 2.4GHz ~ 2.484GHz |
Transmit Power | 2.4GHz 802.11n: ≤20dBm Note: maximum transmission power may vary across different countries subject to local regulatory and regions in which the device is used |
Wireless Function | Fast Roaming Automatic Channel Assignment Transmit Power Control Airtime Fairness Maximum Client Connection Setting Wireless Schedule Reboot Schedule |
Wireless Function | Fast Roaming Automatic Channel Assignment Transmit Power Control Airtime Fairness Maximum Client Connection Setting Wireless Schedule Reboot Schedule |
Wireless Security | Captive Portal Authentication MAC Address Authenticaton Wireless Isolation Between Clients SSID to VLAN Mapping WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK |
