Totolink S505 5-Port 10/100Mbps Desktop Switch



S505 is a Fast Ethernet Switch that designed for general home or small office use. It provides 5 10/100Mbps ports and all ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, the mini desktop design is easy carrying for portable use. So it is an idea solution for small groups.



Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3x standards, S808 provides 5 10/100Mbps port with support of Auto-MDI/MDIX greatly expands network capacity and simplifies cable deployment.



No configuration required, simply plug and play for easy use. You're allowed to add up to seven devices using Ethernet cable to expand your wired home network.





5 10/100Mbps auto-negotiated RJ45 ports.

Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode.

Mini plastic design supports desktop placement or wall mount.

1K entry MAC address table and automatic address learning.

Auto-MDI/MDIX eliminates the need for crossover cables.

Store- and-Forward switching scheme.

Performs non-blocking full wired speed.



BRAND TOTO LINK

MODEL S505

COLOR White

STANDARDS IEEE 802.3, IEEE 802.3u, IEEE 802.3x

INTERFACE 5*10/100Mbps auto-negotiation RJ-45 Ports (Auto MDI/MDIX)

LED 1* Power, 5*LANs

MAC ADDRESS LEARNING Auto-learning, auto-aging

MAC ADDRESS TABLE 1K

NETWORK MEDIA 10BASE-T: UTP Cat 3 or above cable

100BASE-TX: UTP Cat 5, 5e or above cable

BACKUP BANDWIDTH 1Gbps

TRANSMISSION METHOD Store-and-forward

POWER SUPPLY 5V DC/0.6A

ENVIRONMENT Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)

Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

PRODUCT DIMENSIONS 84 x 54 x 25 mm

WEIGHT 300 g

SALES PACKAGE

IN THE BOX S505 Desktop Switch *1

Power Adapter

Ethernet Cable *1

Quick Installation Guide *1

WEIGHT 450.0000
