Aspect Ratio | 16:9 |
Audio | 2x5W |
Brightness | 2,400 ANSI lumens |
Color Wheel | RGBRGB 6 segment color wheel |
Compatible Aspect Ratio | 16:9 (native), 4:3 and LBX compatible |
Connections | HDMI 2.0 (w/ HDCP 2.2, MHL 2.1), HDMI 1.4a, VGA-in, audio-in (3.5mm), audio-out, S/PDIF out (optical), USB 2.0 (service port), USB power, RJ-45, RS-232C, 12V Trigger |
Contrast Ratio | Up to 500,000:1 with Dynamic Black |
Display Technology | Single 0.47” TRP S450 4K UHD DMD DLP® Technology by Texas Instruments™ |
Displayable Colors | 1.07 billion |
Image Size | 34.1” – 302.4 (34.1” to 140” optimal image size) |
Keystone Correction | ± 40° Vertical |
Light Source Type | 240W |
Light Source Life | 4,000/10,000/15,000 (Bright/ECO/Dynamic) |
Lens Shift | Vertical: +15% |
Maximum Resolution | 4K (4096 x 2160) @ 30Hz |
Native Resolution | UHD (3840 x 2160) |
Noise Level | 25/28dB (Eco/Bright) |
Offset | 100% (see Vertical Lens Shift) |
Operating Temperature | 41–104°F (5–40°C), 85% max humidity |
Power Consumption | 317W typical (Bright mode), 348W max (Bright mode), 259W typical (Eco+ mode), 285W max (Eco+ mode) |
Power Supply | AC input 100-240V, 50-60Hz, auto-switching |
Projection Distance | 2.9’ – 34.89’ |
Projection Lens | F=2.5 – 3.26, F=20.91 – 32.62 mm manual focus |
Projection Method | Front, rear, ceiling count, tabletop |
Projection Screen Size | 34.1” – 302.4 (34.1” to 140” optimal image size) |
Remote Control | Full Function Home Remote Control |
Throw Ratio | 1.21 – 1.59 ( with tolerance ±5%) |
Uniformity | 80% |
Zoom Type | 1.3x optical (manual); 0.8 – 2.0 digital |
