Dahua IP Network Camera

2MP Entry IR Fixed-Focal Eyeball Network Camera

Code

: DH-IPC-HDW1230T1P-0280B-S5-QH2

Availability

: In Stock

Rs. 6250
Qty :

Specifications:

Camera
Matrix      1/2.7" 2MP Progressive Scan CMOS
Effective pixels   1920×1080
ROM     16 MB
RAM        64 MB
Scanning system  progressive
Electronic shutter speed  Auto / Manual 1 / 3 s - 1 / 100000 s
Min. lighting  0.01 Lux F2.0
IR distance  30 m (98.4 ft)
IR Control On / Off  Auto / Manual
IR LEDs  one
Pan/Tilt/Rotate Range      Horizontal: 0° - 355°
Vertical: 0° - 78°
Rotation: 0° - 360°
Lens
Lens type  Fixed
Focal length  2.8 mm
Max. diaphragm  F2.0
Viewing angle  105°
diaphragm type  Fixed
closed focal length  0.5 m (1.6 ft)
DURI Distance   Lens   detection  Notification Recognition  Identification
2.8 mm  37.3 m
(122.4 ft)
14.9 m
(48.9 ft)
7.5 m
(24.6 ft)
3.7 m
(12.1 ft)
Video
Video compression  H.265; H.264; H.264H; H.264B; MJPEG
Smart Codec  There is
Video frame rate  Main Stream:
1920 × 1080 (1 fps - 25 / 30 fps
) stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
Streaming capability  2 streams
Permission  1080p (1920×1080); 1.3m(1280×960);720p(1280×720); D1 (704×576/704×480); VGA (640×480); CIF (352×288 / 352×240)
Bitrate control  CBR/VBR
Bit rate H.264: 32Kbps-6144Kbps
H.265: 12Kbps-6400Kbps
Day Night  Auto (ICR) / Color / B / W
BLC  There is
HLC  There is
WDR  DWDR
white balance  Auto / Natural / Street Light / Outdoor / Manual / Regional
Gain Control  Auto / Manual
Noise suppression  3D DNR
Motion Detection  Off / On (4 Zones, Rectangle)
Region of Interest (ROI)  Yes (4 Zones)
Electronic Image Stabilization (EIS)  There is
Smart IR  There is
Image Rotation  0°/90°/180°/270° (Support 90°/270° with 1080p resolution.)
Display  There is
privacy mask 4 Zones
Network
Network  RJ-45 (10/100 Base-T)
Protocol  IPv4; HTTP; HTTPS TCP; UDP; ARP; RTP RTSP; SMTP FTP DHCP DNS; NTP; Multicast
Compatibility  ONVIF (profile G); CGI P2P; Genetec
User / Host  20
Storage  FTP Cloud Dahua
Browser  IE
Chrome
Firefox
Management software  SmartPSS; DSS; DMSS
Smartphones  iOS; Android
Certificates
Certificates  CE-LVD: EN60950-1
CE-EMC: EMC Directive 2014/30/EU
FCC: 47 CFR FCC Part 15 Subpart B
Protection
Degree of protection  IP67
Environment
Operating conditions  -40°C to +60°C (-40°F to +140°F) / Less than ≤ 95% RH
Storage temperature  -40°C to +60°C (-40°F to +140°F)
Electrical properties
Source of power  12V DC / PoE (802.3af)
Power consumption  <4.3W
General information
Frame  Metal + Plastic
Fastening M12
Dimensions  85.5mm × Φ109m (3.4" × Φ4.3")
Net weight  0.24 kg (0.5 lb)
