Specifications:
| Device Type | video recorder |
| Connection type | wired |
| DVR type | hybrid |
| Video standard | IP, HDCVI, HDTVI, AHD, CVBS (Analogue) |
| Record resolution | 2 Mpx (1080n) |
| Recording speed | 1-12 fps |
| Number of channels | 8 |
| Number of analog cameras | 8 |
| Number of IP cameras | 8 |
| Video inputs | 8xBNC |
| Video output | 1xRJ45 |
| Audio inputs | 1xRCA |
| Audio outputs | 1xRCA |
| Incoming Bandwidth | 36 Mbps |
| Outcoming bandwitch | no data |
| Network Interface | 1 RJ-45 (10/100 Mbps), HTTPs, HTTP, TCP/IP, IPv4, UPnP, Onvif 2.6, RTSP, RTCP, UDP, SMTP, SNMP, Multicast, IGMP, NTP, DHCP, DNS, DDNS, FTP, P2P |
| Alarm Inputs-Outputs | no |
| Alarm inputs | no |
| Alarm outputs | no |
| Video compression | H.264, H.264+ |
| CPU | multi-core embedded |
| Streaming | 1 stream |
| Recording modes | constant / schedule / motion detection / alarm |
| Maximum number of users | 5 |
| Mobile applications | iOS, Android |
| Number of HDD | 1 |
| HDD type | Sata up to 8TB |
| HDD storage capacity | 8 TB |
| RAID | no |
| PoE support | no |
| PoE ports | no |
| Wi-Fi support | no |
| HDMI port | 1 |
| VGA output | 1 |
| USB port | 1xUSB 2.0, 2xUSB 2.0 |
| eSata | no |
| RS-232 | no |
| RS-485 | no |
| Intended for use | home, house, office, store, warehouse, production |
| Video Analytics | no |
| Compatibility | Onvif Profile S, SDK |
| Operating voltage | 12V DC |
| Consumption | 10W without HDD |
| Dimensions (WхHхD) | 233x254x42 mm |
| Body color | black |
| Body material | metal |
| Weight | 0.91 kg |
| Temperature range | 0...+50°C |
