ONV0110S-SCXS4 4Port 100M Single mode Single Fiber Media Converter

Suitable for Long-distance Muti-media Schooling,long-distance broadcast television transmission system

Code

: ONV0110S-SCXS4

Availability

: In Stock

Rs. 9000
Qty :

 â—† 4*10/100M RJ45 Ports + 1*155M Fiber Port


â—† Ethernet 10Base-T or 100Base-TX to 100Base-FX fiber optical media converter

â—† Supports IEEE 802.3af, IEEE 802.3, IEEE 802.3U, IEEE 802.3X, IEEE 802.1d standard
â—† Ethernet electrical port supports the consultations between rate and duplex mode, parallel / crossover line adaptive function or enforcement mode
â—† Supports 10Mbps and 100Mbps automatically adaptive (Working bandwidth can be 200Mbps in full-duplex mode)
â—† Features with link loss diagnosis, electrical port link diagnosis and optical port link diagnosis, dynamic data transmission, full-duplex/half-duplex, speed indicator

â—† Supports super long frame transmission, fully compatible with various expansion standards data frame

â—† Supports optical path interruption transfer function, and transfer the interruption-alarm to the opposite equipment

â—† Provides single/dual fiber transmission, many optical interface configuration for different wavelength and LED power,etc.

â—† Various status indicators, can easily and accurately show the working status of the interface and link
